Viking® 3 Series 30" Antique Bronze Liquid Propane Gas Dual Fuel Range

Product Overview

Features and Functions

Wide variety of BTU ratings to accommodate all types of surface cooking needs – including a NEW fifth burner

Left front – 18,000 BTU

Left rear – 9,100 BTU

Center – 9,100 BTU

Right front – 17,000 BTU

Right rear – 12,000 BTU

Sealed burners with porcelainized, cast-iron burner caps

Exclusive – SureSpark™ Ignition System

Automatic electric spark ignition/re-ignition; surface burners light at any position on the knob and re-light if extinguished even on lowest setting

Exclusive – largest oven cavity in the industry

4.7 cu. ft. overall

4.1 cu. ft. measured to AHAM standard (See specifications chart for oven interior dimensions)

High performance cooking modes include Bake, Convection Bake, TruConvec™ Convection Cook, Convection Roast, Hi Broil, Medium Broil, Low Broil, Convection Broil, Convection Dehydrate, and Convection Defrost

Exclusive – Patented Vari-Speed Dual Flow™ Convection System has the largest convection fan in the industry; the 8-1/2” fan works bi-directionally for maximum airflow and excellent cooking results

Concealed 10-pass dual bake element provides precise temperature control

10-pass broiler with heat reflector provides superior broiling performance

Rapid Ready™ Preheat provides super fast preheating

Oven has six porcelain-coated rack supports and comes standard with one TruGlide™ full extension oven rack and two standard racks

Halogen oven lighting provides excellent visibility throughout oven cavity

Shipped standard with island trim

Accessory portable griddle/grill (RDPGD) available for use over center burner

Easy Operation and Cleanup

Extremely large self-clean convection oven

Permanently sealed burners – spills cannot enter the one-piece tooled and porcelainized burner box

Durable metal die-cast knobs with child-proof, push-to-turn safety feature

Customer removable knobs, grates, and burners/caps for easy cleaning

Grate design provides continuous cooking surface for easy movement of pots and pans

Installation Accessories

6” high backguard (RD301BG6SS)

Countertop side trim (RD24CSTSS)

Countertop rear trim (P30CRTSS)

Curb base and custom curb base front (P30CBF4SS)

LP conversion kit (RDLPKR2)

Natural Gas conversion kit (RNKR2)
